CDVI Galeo - Wiring Diagram GALEO 3 Relay Outputs; GALEO 3 Relay Outputs Wiring Details

V V
R1
P3
P2
C1 T1
R2
C2 T2
R3
C3 T3 P1 M P2 PX H H + - E
P1 P2 H
V
V
VV
D - 693 : Remote electronics
P3jumperallows
totheusertomodify
itsownPincode.
Toenablethisfeatureput
thejumperon.
(seeProgrammingsection
intheinstructionmanual)
P2 jumper resets the
keypad to factory default
values.Removethepower
from the keypad then put
thejumper.
(see Programming section
intheinstructionmanual)



P1request-to-exitinputactivatesrelay1.
P2request-to-exitinputactivatesrelay2.
Latchortoggledoutput.



Whenthecontactisopen
thentherequest-to-enterisdisabled.
Whenthecontactisclosedthenpress
anykeyonthekeypadtoenter.
7
cdvi.se
cdvigroup.com

IlluminatedWeatherproofKeypadwithremoteelectronics
 

12to24VAC
or12to48VDC
Failsafelock

Keypadmode

Request-to-
Entermode






White
Brown
Greenorblue
Failsecurelock
Varistor

Accordingtolock
specications
 

Inputvoltage12Vto24VACor12Vto48VDC

Inputvoltage12Vto24VACor12Vto48VDC

N/Ccontactrelay1

Commonrelay1

N/Ocontactrelay1

N/Ccontactrelay2

Commonrelay2

N/Ocontactrelay2

N/Ccontactrelay3

Commonrelay3

N/Ocontactrelay3

Request-to-exitinputrelay1

Commonofinputs

Request-to-exitinputrelay2

TimerContact

Whitewirefromkeypad

Brownwirefromkeypad

GreenorBluewire(illumination)
