III. PROCEDURE DE MONTAGE DU PROFIL 100 EC
Drill (bit Ø6MM) the 2 mounting holes (depth minimum = 35MM) and
the wiring access area.
Insert the S5 2 plastic anchors in the holes.
Mount the back plate of the PROFIL 100 EC with the M4x30 screws.
Insert the cable of the PROFIL 100 EC in the wiring access area.
Place the keypad on the back plate top first and then make sure that it
fits on the back plate.
Close the keypad with the DIAX
®
M5x8 screw and the DIAX spanner.
To mount the remote electronics box, it is suggested to use the
plastic bracket.
Plots de sortie Correspondances
Terminal
Description
V Input voltage 12/24 VAC or 12/48 VDC
V
I l 12/24 VAC 12/48 VDC
1
2
3
4
R
