CDVI PROFIL 100 EC - WIRING DIAGRAM PROFIL100 EC 2 and 3 relay outputs

Edition 09/2006 G0301FR0270V01
8
WIRING DIAGRAM PROFIL100 EC 2 and 3 relay outputs
V : Varistances
P1 P2
230V
V
Strike fail secure
Input voltage
According to lock
s
p
ecifications
2
Green
Brown
White
230V
2
P2: Place jumper for reset
P3: Individual Code
modification by user
Distance
10 meters
maximum
4
V
Magnet / Strike fail safe
V V R1 C1 T1 R2 C2 T2 R3 C3 T3 P1 M P2 Px H H + - E
RL1
P3 P2
ST1
V
RL2 RL3
Input voltage
12 to 24 V AC
or 12 to 48 VDC
Strike fail secure
Yellow
