12] LED CONFIGURATION ON CENTAUR SYSTEM
GREEN LED
SETTINGS
RED LED
SETTINGS
LED ACTUATION :
GREEN
ACCESS ALLOWED
RED
ACCESS DENIED
BLUE
ST
AND-BY
* In Digicode
®
keypad mode only or Proximity mode only.
11] ARK 8 BITS OUTPUT FORMAT
Keypad input
Hexadecimal
Binary Datas
0
FO
11110000
1
E1
11100001
2
D2
11010010
3
C3
11000011
4
B4
10110100
5
A5
10100101
6
96
10010110
7
87
10000111
8
78
01111000
9
69
01101001
*
ou A
5A
01011010
#
ou B
4B
01001011
6
cdvigroup
.com
EN
SOLARKPW-SOLARKPB
Dual Technology Digicode
®
/Proximity reader - Wiegand
INSTALLATION MANUAL
5
7
