CDVI SOLARKPW User Manual

15] PROGRAMMING CHART
Code length:
- 7 digits allowed in 30 or 44 bits only,
- 8 digits allowed in 44 bits only.
Permanent Mode:
The keypad is permanently illuminated
and the reader is ON.
Default values
- Illumination duration: 10 seconds
(in standard mode),
- User code lenght: 5 digits,
- 44 bit wiegand output in direct mode,
- Buzzer abled,
- permanent mode keypad + tags.
- master code 1 2 3 4 5 (default value).
Audible Signal
- 1 short beep > keypad powered
and key presses,
- 1 long beep > data computing
in programming,
- 2 short beeps > Entry or Exit
from programming,
- 4 short beeps > data computing error.
1 beep = OK
Green LED ON
4 beeps = Error
1 bip
LED verte ON
A4
Programming
mode
Enter:
- 0 = for hexadecimal
mode (A & B are not
used) > Atrium & Centaur
standard (26 bits)
- 1 = for decimal mode
(Direct mode, A is
allowed) > Centaur
only. Digicode protocol
(Program the code in
the fi eld PIN)
- 2 = for ARK mode
1 beep
Green LED ON
1 beep = OK
Green LED ON
4 beeps = Error
Enter the illumination
time in seconds from
02 to 99 seconds
A0
Programming
key-in keypad
time
1 beep = OK
Green LED ON
4 beeps = Error
1 beep
Green LED ON
Enter: 4, 5, 6, 7 or 8
to specify the number
of digits.
A1
Programming
the code lenght
1 beep = OK
Green LED ON
4 beeps = Error
1 beep
Green LED ON
Enter: 26, 30 or 44
to defi ne the Bit number
of the Wiegand format
A2
Programming
the Bit length
8 cdvigroup.com
EN
SOLARKPW-SOLARKPB
Dual Technology Digicode
®
/Proximity reader - Wiegand
INSTALLATION MANUAL

CDVI SOLARKPW Specifications

General

Brand	CDVI
Model	SOLARKPW
Category	Card Reader
Language	English
