Cebora MIG WELDER - Page 7

7
ART DESCRIPTION
1 COVER
2 RUBBER MAT
3 FLANGE
4 SPACER
5 DRIVE ROLL
6 WIRE FEED MOTOR
7 CIRCUIT BOARD
8 HINGED SIDE PANEL
9 CLOSING
10 WASHER
11 ADAPTOR
12 PRESSURE SPRING
13 KNOB
14 CENTRE DEVIDER
15 KNOB
16 RUBBER PROTECTION
ART DESCRIPTION
33 SOLENOID VALVE
34 FITTING
35 BELT
36 SUPPORT
37 COIL SUPPORT
38 SUPPORT
39 RECTIFIER
40 REINFORCEMENT
41 MOTOR
42 FAN
43 SWITCH
44 TRANSFORMER
45 THERMOSTAT
46 SUPPORT
ART DESCRIPTION
17 KNOB
18 RUBBER PROTECTION
19 FRONT PANEL
20 EARTH CABEL
21 SWIVELLING WHEEL
22 FIXED SIDE PANEL
23 COVER
24 WHEEL
25 AXLE
26 SUPPORT
27 UNDERCARRIAGE
28 WIRE PRESSURE CLAMP
29 INPUT POWER CABLE
30 BACK PANEL
31 SUPPORT
32 FITTING
