ENGLISH
Before installing the hob
- Make sure the worktop in which you install the hob is levelled, complies with the space
requirements and is made of a heat-resistant and insulated material.
- If you install the cooking hob over an oven, the latter must have a cooling fan.
- The installation must comply with all the safety requirements and the applicable rules and
regulations.
- The main wiring is tted with a suitable isolating switch that allows complete disconnection
from the mains, which has been installed and positioned in accordance with local wiring
rules and regulations.
- The isolating switch must be of an approved model and provide 3 mm contact separation
on all poles (or on all active [phase] conductors if local wiring regulations allow this
variation of requirements).
- If in doubt about the installation, seek advice from local building authorities and regulations.
- Use heat-resistant and easy-to-clean nishes (such as ceramic tiles) on the walls
surrounding the hob.
After installing the hob
- The power cord should not be accessible through the cabinet doors or drawers.
- Make sure that there is an adequate ow of fresh air from the exterior of the cabinet to
the hob base.
- If the hob is installed above drawers or cabinets, you must install a thermal protection
barrier under the hob base.
- The user must be able to access the isolating switch easily.
Fixing brackets
- You must place the hob on a stable and smooth surface (you can use the packaging). Do
not apply force to the buttons protruding from the hob.
- Screw the four brackets to the bottom of the hob, then install the latter in the worktop
recess (as shown in Figure 7).
- Adjust the bracket position to the thickness of the worktop. Fig. 8
Fig. 8
1. Induction hob
2. Maintenance
3. Worktop
Warning
Brackets should not, under any circumstance, touch the interior surfaces of the worktop after
installation. Fig. 8
- It is recommended that qualied personnel or technicians install the hob. You should not
