BOLERO SQUAD I 3000
59
ENGLISH
Note
The safety distance between the sides of the hob and the interior surfaces of the worktop
must be at least 3 mm.
Fig. 3
L (mm) W (mm) H (mm) D (mm) A (mm) B (mm) X (mm) F (mm)
590 520 62 58 560 490 50 min. 3 min.
In any case, make sure the induction hob is well ventilated and the air inlet and outlet are not
blocked. Make sure the induction hob works correctly. Fig. 4
Note
The safety distance between the hob and a cabinet over the hob must be at least 760 mm. Fig.
5
Fig. 4
A (mm) B (mm) C (mm) D E
760 Min. 50 Min. 20 Air inlet Air outlet 5 mm
Proper ventilation
Fig. 6
To avoid accidental contact with the bottom of the hob while it is hot, or receiving an unexpected
electric shock during use, it is necessary to place a wooden insert, xed with screws, at a
minimum distance of 50 mm from the bottom of the hob. Follow the indications on gure 6.
Warning
- There are ventilation gaps around the exterior of the hob. You must ensure these gaps are
not blocked by the worktop when placing the hob.
- Please note that the glue that binds the plastic or wooden material to the furniture must
withstand a temperature of more than 150ºC to prevent the coating from peeling o.
- The rear wall and the adjacent and surrounding surfaces must be able to withstand a
temperature of 90ºC.
Before installing the hob
- Make sure the worktop in which you install the hob is levelled, complies with the space
requirements and is made of a heat-resistant and insulated material.
- If you install the cooking hob over an oven, the latter must have a cooling fan.
- The installation must comply with all the safety requirements, and the applicable rules
and regulations.
02502_Placa Bolero Squad I 3000 _IM_YV_01220125.indd 5902502_Placa Bolero Squad I 3000 _IM_YV_01220125.indd 59 10/2/22 17:3610/2/22 17:36
