ENGLISH
1. PARTS AND COMPONENTS
Fig. 1
1 Cooking area 1 (1300/1500 W)
2 Cooking area 2 (2300/2600 W)
3 Cooking area 3 (3000/3600 W)
4 Glass plate
5 Control panel
6 On/o button
Control panel
Fig. 2
1 On/o button
2 Timer
3 Boost
4 Cooking area selection buttons
5 Power/timer setting button
6 Lock button
2. BEFORE USE
- This product includes a package designed to protect it during transport. Unpack the
appliance and keep the original packaging and materials in a safe place. It will help prevent
any damage if the product needs to be transported in the future. In case the original
packaging is disposed of, make sure all packaging materials are recycled accordingly.
- Make sure all parts and components are included and in good conditions. If there is any
piece missing or not in good condition, immediately contact the Technical Support Service
of Cecotec.
3. INSTALLATION
Selection of the installation tools
- Cut out the worktop where the hob is to be tted according to the dimensions given in the
table below and gure 3.
- For its installation and use, you must keep a space of at least 5 cm around the gap.
- Make sure the worktop thickness is at least 30 mm. Select a worktop with a heat-resistant
and insulated material (wood or other similar brous or hygroscopic materials should not
be used as worktop material unless impregnated) to avoid electric shock or deformation
caused by heat radiation from the hob.
