User manual A100RC+ v1.0EN
1. Pack contents
• 1 control panel A100RC+ with 4 channels radio remote control "BRiO®"
• 1 bag containing
– 4 screws and 4 dowels (control box + wall holder for the radio remote control)
– wall holder for the radio remote control
• User manual (this document)
2. Technical characteristics
Output Voltage 12V ~ AC 50/60Hz
Input Voltage 220V AC
Power consumption 5W maximum
Switching power (connected lights) 100W maximum
Transformer power 100VA
Protection rating IP-55
Dimensions 148x256x84 mm
Installation
Control box : wall fixation (2 supplied screws/
dowels)
Wall holder for the remote control : Wall fixation
(2 supplied screws/dowels)
Weight
Control box : 390 g / remote control : 40 g
Complete cardboard box : 600 g
Radio remote control
4 channels - Frequency : 433,92Mhz
Battery : alkaline 12V 23A
Power consumption when sending: 18mA max
Power < 0,1 mW- in-built antenna
Range 30m max free field
www.c-
cei.fr
