Celestron FlipView 44314 - Page 3

ENGLISH 3
PARTS
1. Shutter trigger
2. Flip out LCD screen
3. Flip out leg
4. Settings button
5. Color mode button/up button
6. Playback/left button
7. Illuminator adjustment wheel
8. Battery compartment
9. Zoom control button
10. 5 V AC in port
11. Mini USB port
12. Video out port
13. Micro SD card slot
14. Battery charge indicator
15. OK button
16. Down button
17. On/Off switch
18. Focus wheel
19. Microscope barrel
20. ¼-20” threaded insert
20
7
8
18
19
3
9
10
11
12
13
14
15
16
17
1
2
4
5
6
