REV. 01
10 / 28
CHAPTER 4 – INSTALLATION
4.1 SPACE REQUIRED
When choosing the place of installation be sure that it complies with current safety
at work regulations.
• The tire changer must be connected to the main electric power supply and the compressed air
system. It is therefore advisable to install the machine near these power sources.
• The place of installation must also provide at least the space shown in pictures 4 - 4/A so as to
allow all parts of the machine to operate correctly and without any restriction.
• If the machine is installed outside it must be protected by a lean-to.
The tire changer with electric motor cannot be used in explosive atmospheres,
unless it is a proper version.
