Cembre ROLLY 2000 - Printer Installation; Device Overview

6
2.1 Device overview
2
3
5
6
7
4
1
8
9
10
1 Cover
2 Core adapter
3 Margin stop
4 Roll retainer
5 Ribbon supply hub
6 Ribbon take-up hub
7 Print mechanics
8 Mounting area for accessories incl.
peripheral connector
9 Navigator pad
10 Display
Fig. 1 Overview
13
14
15
19
20
17
12
16
18
12 Ribbon guide
13 Printhead locking screw
14 Printhead retainer with printhead
15 Print roller
16 Allen key
17 Printhead locking lever
18 Plate
19 Axle with guide ring
20 Label sensor
Fig. 2 Print mechanics
2 Installation
