Page 14 <&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1 Item 63873
?@<6AQ RS6;@ACRE D@CEA6E@ET6@??6DUGQ
SG6@?6%;6@X%AB6%<RGGRVCEW%T@;6<FGGQ
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
S,($#%G"#$%,89%X",3(,5
S,($#%G"#$
S,($ X*#4("/$"&8 l$>
1 Bottom Housing 1
2 Motor 120VAC/0.5A 1
3 Transformer 1
4 Front Housing 1
5 Front Plate 1
6 Power Switch 1
7 MCU PCB 1
8 Tapping Screws 5
9 Power PCB 1
10 Heat Sink 1
11 Back Housing 1
12 Red Positive Cable 1
13 Power Cord 1
14 Black Negative Cable 1
15 Handle Cover 1
16 Handle 1
17 Bolt M5X16 6
18 Tapping Screws ST4.2X32 4
19 Tapping Screws ST4.2X22 22
20 Side Housing 2
21 Wheel 2
22 Hubcap 2
S,($ X*#4("/$"&8 l$>
23 Foot 1
24 Tapping Screws 4
25 Control Panel 1
26 Cable Storage Peg 2
27 Tapping Screws 4
28 Black Wire 1
29 White Wire 1
30 Black Wire 1
31 Black Wire 1
32 Blue Wire 1
33 White Wire 1
34 Black Wire 1
35 Red Wire 1
36 Nut M4 6
37 Circuit Breaker 2
38 Copper Connection Strap 3
39 Nut M5 5
40 Bolt M5x12 6
41 Cotter Pin 4
42 Axle (not shown) 1
43 Bracket (not shown) 2
;*4&(9%S(&9'4$m#%?*(",7%E'5+*(%B*(*-%
E&$*- If product has no serial number, record month and year of purchase instead.
E&$*- Some parts are listed and shown for illustration purposes only, and are not available individually
as replacement parts. Internal parts are not user-serviceable and are not available.
