10� If any DTCs were detected then the
red light will illuminate and total
number of Fault Codes followed by
the Pending Codes will be displayed:
FAULT: 09
PEND: 04
Figure J: Example of detected DTCs
Note: If the yellow light illuminates wait
for the Code Reader to finish its analysis�
11� View each DTC by pressing SCROLL�
a� The first DTC will appear on the top
line and the bottom line will show the
numerical sequence of the DTC and
the total number of DTCs stored�
b� The example below indicates
“PO108” is first DTC in a
sequence of nine stored DTCs�
P0108
01/09
Figure K: Example of a stored DTC
12� Press SCROLL to move through
the other stored DTCs�
13� A pending code will be
shown ending in “PD�”
P0008 PD
05/09
Figure L: Example of a pending code
14� To view previous DTCs, press
SCROLL to move forward through
the list� After the last DTC is
displayed, the list will restart from
the beginning at the next press�
15� See “DTC Definitions” starting
on page 165 to interpret data�
