Page 14 For technical questions, please call 1-888-866-5797. Item 64981

Viewing VIN Number

The view VIN function retrieves the

Vehicle Identification Number on 2002 and

newer vehicles that support Mode 9�

1� From the Main Menu, scroll until

“4� VIN” is displayed� Select

it by pressing ENTER/Exit�

4. VIN

Figure R: VIN Screen

2� Press SCROLL to view the

vehicle’s 17-digit VIN�

1HGBH41JXMN11219

Figure S: VIN example

a� A flashing right arrow indicates

additional digits of the VIN string

are available on the next screen�

1HGBH41JXMN11

Figure T: More digits next screen

b� A flashing left arrow indicates

additional digits of the VIN string are

available on the previous screen�

1HGBH41JXMN11

Figure U: More digits previous screen

Rescanning Data

The Rescan function:

• Retrieves the most current data stored

in the EMC (Engine Control Module)�

• Or, is used to relink the the

Code Reader to the vehicle

if the communication is

disrupted/disconnected�

1� From the Main Menu, scroll until

“5� RESCAN” is displayed� Select

it by pressing ENTER/Exit�

5. RESCAN

Figure V: Rescan

2� Press ENTER/Exit to perform a

Rescan/relink or SCROLL to abort

and return to the Main Menu�
