Page 7Item 96308
For technical questions, please call 1-888-866-5797.
Measuring AC Voltage
1. Insert the plug of the Black Test Lead into the COM jack. Insert the Red Test Lead
into the Red jack.
2. Set the Rotary Switch to the 300V~ position.
3. Connect the Red Test Lead to the hot source or load to be measured, and the Black
Test Lead to the neutral source to be measured.
4. Read the voltage value (V~) on the LCD Screen.
Measuring AC Current
1. Set the Rotary Switch to the desired AC current range.
2. Press the Trigger to open the Clamp Jaw. Clamp the Jaw on one of the wires to be
tested. Keep the wire in the center of the Jaw. NOTE: Only one wire can be tested at
a time, or else the readings from two wires will cancel each other and result in a false
reading.
3. CAUTION! Do not touch current bearing AC wires with your hand.
4. Read the reading on the display.
