Page 9Item 96308
For technical questions, please call 1-888-866-5797.
Measuring for Continuity
1. Insert the plug of the Black Test Lead into the COM jack. Insert the Red Test Lead
into the Red jack.
2. Set the Rotary Switch to the continuity position.
3. Connect the Red Test Lead to the hot source or load to be measured, and the Black
Test Lead to the neutral source to be measured.
4. Read the resistance value on the LCD Screen. NOTE: The buzzer will sound if
measured resistance is less than approximately 30 Ohms.
Measuring a Diode
1. Insert the plug of the Black Test Lead into the COM jack. Insert the Red Test Lead
into the Red jack. NOTE: The polarity of the Red Test Lead is “+”.
2. Set the Rotary Switch to the diode position.
3. Connect the Red Test Lead to the anode of the diode, connect the Black Test Lead to
the cathode of the diode.
4. Read the approximate forward voltage on the LCD Screen. NOTE: The reading units
are “mV”.
