Page 8Item 96308
For technical questions, please call 1-888-866-5797.
Measuring Resistance
NOTE: Before measuring resistance, be sure the power to the circuit has been
disconnected and all capacitors have been discharged.
1. Insert the plug of the Black Test Lead into the COM jack. Insert the Red Test Lead
into the Red jack.
2. Set the Rotary Switch to the desired resistance range, either 2000 Ohms or 200
kOhms.
3. Connect the Red Test Lead to the hot source or load to be measured, and the Black
Test Lead to the neutral source to be measured.
4. Read the resistance value on the LCD Screen.
5. NOTE: The buzzer will sound if measured resistance is less than approximately 30
Ohms with the rotary switch in the 2000 Ohm position.
