6) “ ” -- Indicates battery volume.
3.5 Keyboard
No solvents such as alcohol are allowed to clean the keypad or display.
Use a mild nonabrasive detergent and a soft cotton cloth. Do not soak
the keypad as the keypad is not waterproof.
3.6 Power
Internal Battery Power
The scan tool has a 9V cell battery that provides power for off-car
reviewing and analysis. Press the power key to turn on the scan tool.
When the “
” icon appears, replace the battery as instructed in
“Battery Replacement” on paragraph 3.10.
• If the scan tool is stored for a long period of time, remove
batteries to prevent battery leakage from damaging battery
compartment.
External Power
External power of the scan tool is provided via the vehicle Data Link
Connector (DLC). Just follow the steps below to turn on the scan tool:
1) Connect the OBD II Cable to scan tool.
2) Find DLC on vehicle.
• A plastic DLC cover may be found for some vehicles and you
need to remove it before plugging the OBD2 cable.
3) Plug OBD II cable to the vehicle’s DLC.
3.7 Code Lookup
The Code Lookup function is used to search for definitions of
DTCs in built-in DTC library.
1) From Main Menu, use UP/DOWN scroll button to select DTC
Lookup and press ENTER button.
11
