Erase Codes
Erase Done!
Press any key to con.
z If the codes are not cleared, then an “Erase Failure. Turn Key
on with Engine off!” message appears.
Erase Codes
Erase Failure.
Turn Key on with
Engine Off!
Press any key to con.
P k t
4) Press any button to return to Diagnostic Menu.
5.3 Viewing Freeze Frame Data
1) To view freeze frame data, use UP/DOWN scroll button to select
View Freeze Frame from Diagnostic Menu and press ENTER
button.
……… …Diagnostic Menu…… ………..
3/6
Read Codes
Erase Codes
►View Freeze Frame ?
I/M Readiness
Vehicle Info.
Unit of Measure
2) Wait a few seconds while the scan tool validates the PID MAP.
