4.4 DC Voltage Measurement:
WARNING!
Maximum Input Voltage is 600V AC/DC. Do not attempt to
Take any voltage measurement that may exceed to avoid
Electrical shock hazard and/or damage to this instrument.
Switch the main function selector to V range.
Connect red test lead to “+” terminal and black one to the
“ COM “ terminal.
Measure the voltage by touch the test lead tips to the test
circuit where the value of voltage is needed.
Read the result from the LCD panel.
9
