4.6 Continuity Test:
Switch the main function to
range.
11
Connect red test lead to “+” terminal and black one to the
“ COM ” terminal.
Connect tip of the test leads to the points where the
conduction condition needed.
If the resistance is under 40Ω, the beeper will sound
continuously.
Beeper
© Short circuit © Open circuit
