II. Specification
General Specification:
Digital Display:
3 3/4 digits LCD display with maximum reading 3999
Analog Display:
42 segments fast analog bar display
Symbol and Scale range:
Adjust automatically according range and input signal
Polarity:
When negative signal in apply to the tester,
will show.
Over Load:
When the signal larger than the maximum will be show
Sample Rate:
2 times/sec for digital data
20 times/sec for analog bar
Low Power Indication:
When the battery is under the proper operation range,
will appear on the LCD display.
Power Source: UM-4 or AAA 1.5V battery x 2.
Power life: Approx. 50hr (Alkaline Battery )
Auto Power Off:
If there is no key or dial operation for 30 minutes, the meter
will power itself off to save battery consumption. This
function can be disabled by press and hold the ZERO
button then power the unit on.
Clamp opening size: 30mm
Dimension (L x W x H) :
193 x 50 x 28mm, 7.60 x 1.97 x1.1 inch
Weight: 240g, 8.46
OZ ( include battery)
Accessory:
Instruction Manual, Leather Case, Test lead, Battery 1.5Vx2
2
