Page 12 For technical questions, please call 1-800-444-3353. Item 47016
67181
NOTICE
Clean the Spray Gun IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Spray Gun.
User-Maintenance Instructions
Procedures not specifically explained in this manual
must be performed only by a qualified technician.
TO PREVENT SERIOUS INJURY:
Detach the air supply and safely discharge any residual air pressure in the tool
before performing any inspection, maintenance, or cleaning procedures.
TO PREVENT SERIOUS INJURY FROM TOOL FAILURE:
Do not use damaged equipment. If abnormal noise, vibration, or leaking
air occurs, have the problem corrected before further use.
Inspection
Note: These procedures are in addition to the regular checks and maintenance
explained as part of the regular operation of the air-operated tool.
BEFORE EACH USE, inspect the general condition of the tool. Check for:
• loose screws,
• misalignment or binding of moving parts,
• clogged nozzle,
• damaged air supply hose,
• cracked or broken parts,
• damaged electrical wiring, and
• any other condition that may
affect its safe operation.
Cleaning
Solvent Selection
Follow the paint manufacturer’s
recommendations for cleaning, solvent type,
and disposing of used solvent.
•Latex Paints: Do not use
this Spray Gun with latex paint.
IMPORTANT: Do not use mineral spirits
on latex paints or the mixture will congeal,
making it very difficult to remove.
•Oil Based Paints: Use mineral spirits.
WARNING! TO PREVENT FIRE,
IF A FLAMMABLE SOLVENT
NEEDS TO BE USED,
ADHERE TO THE FOLLOWING:
a. Follow solvent manufacturer’s clean up
instructions and safety precautions.
b. Flush Spray Gun a full hose
length from air compressor.
c. If collecting flushed solvents in
metal container, transfer to nonmetal
container, and flush metal container.
d. Work far away from any ignition
sources in a vapor free area.
e. Keep class ABC fire extinguisher nearby.
After each use:
1. Empty the Cup and clean it with the solvent.
2. Fill the Cup with solvent and spray it through
the Spray Gun into a container, while shaking
the Spray Gun. Once the Cup is empty, repeat
the process until the solvent comes out clean.
3. Disconnect from the air source.
4. After disconnecting, point the Spray Gun into
the spent solvent container and squeeze the
Trigger again to make sure no air remains.
SAFETY OPERATION MAINTENANCESETUP
