Page 8 For technical questions, please call 1-800-444-3353. Item 60328
NOTICE
Clean the Airbrush IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Airbrush.
SAFETY OPERATION MAINTENANCESETUP
5. If you are using one extension cord for more
than one tool, add the nameplate amperes
and use the sum to determine the required
minimum cord size. (See Table A.)
6. If you are using an extension cord
outdoors, make sure it is marked with the
suffix “W-A” (“W” in Canada) to indicate
it is acceptable for outdoor use.
7. Make sure the extension cord is
properly wired and in good electrical
condition. Always replace a damaged
extension cord or have it repaired by a
qualified electrician before using it.
8. Protect the extension cords from sharp
objects, excessive heat, and damp or wet
areas.
TABLE A: RECOMMENDED MINIMUM WIRE GAUGE
FOR EXTENSION CORDS* (120/240 VOLT)
NAMEPLATE AMPERES
(at full load)
EXTENSION CORD LENGTH
25´ 50´ 75´ 100´ 150´
0 – 2.0 18 18 18 18 16
2.1 – 3.4 18 18 18 16 14
3.5 – 5.0 18 18 16 14 12
5.1 – 7.0 18 16 14 12 12
7.1 – 12.0 18 14 12 10 -
12.1 – 16.0 14 12 10 - -
16.1 – 20.0 12 10 - - -
* Based on limiting the line voltage drop to five volts at 150% of the
rated amperes.
Specifications
Compressor
Electrical Rating 120V~ / 1.1A
Motor Speed 1,750 RPM
Power Cord 6'
Maximum Air Pressure 58 PSI
Air Outlet 1/8" - 27 NPT
Air Output 0.7 CFM @ 40 PSI
Airbrush
Working Air Pressure 25 - 60 PSI
Air Inlet 1/8" - 27 NPS
Nozzle Size .35mm
Spray Pattern Hairline to 1-1/2" Wide
Glass Jar Capacity 3/4 oz. (22cc)
Air Consumption 0.7 CFM @ 40 PSI
