Central Pneumatic 68152 - Parts List and Diagram

Page 18 For technical questions, please call 1-800-444-3353. Item 68152
SAFETY OPERATION MAINTENANCESETUP
Parts List and Diagram
Parts List
Part Description Qty
1 Housing 1
2 Casing 1
3 Spring 1
4 O-Ring 1
5 Valve Stem 1
6 O-Ring 1
7 O-Ring 1
8 O-Ring 1
9 Valve Body 1
10 Bracket 1
11 Trigger Screw 1
12 Nut 1
13 Trigger 1
14 Spring Washer 1
15 Nut 1
16 Air Regulator 1
17 O-Ring 4
18 Retainer Ring 1
19 O-Ring 1
20 Air Inlet Nut 1
21 Retainer Ring 1
22 Washer 1
23 Bearing (#62002) 2
24 Cylinder Side Plate 2
25 Cylinder 1
26 Pin 1
27 O-Ring 1
Part Description Qty
28 Rotor 1
29 Rotor Blade (Vane) 5
30 Work Spindle 1
31 Woodruff Key 1
32 Rear Gasket 1
33 Rear Cover 1
34 Spring Washer 5
35 Screw 2
36 Screw 2
37 Balancer 1
38 Screw 1
39 Spring Washer 1
40 Nut 1
41 Bushing 1
42 Spindle Lock 1
43 Washer 1
44 Washer 1
45 Screw 1
46 Screw 1
47 Washer 1
48 Bearing (#62012) 1
49 Washer 1
50 Retainer Ring 1
51 Drive Spindle 1
52 Backing Pad 1
53 Handle 1
54 Air Inlet Plug (not shown) 1
