Page 18 For technical questions, please call 1-800-444-3353. Item 69704
NOTICE
Clean the Spray Gun IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Spray Gun.
Part Description Qty
1 Air Cap 1
2 Lock Ring 1
3 Brass Ring 1
4 Fluid Nozzle 1
5 Trigger Bolt 1
6 Gasket 1
7 Trigger 1
8 Gun Body 1
9 Pattern Valve Seat 1
10 Pattern Control Knob 1
11 Pattern Needle 1
12 Gasket 1
13 O-Ring 1
14 Needle Spring 1
15 Needle Holder 1
16 Fluid Control Knob 1
17 Needle 1
18 Needle Screw 1
19 Needle Seat 1
20 Air Inlet Coupling 1
21 Air Valve Spacer 1
22 O-Ring 1
Part Description Qty
23 Air Valve 1
24 Air Spring 1
25 Air Valve Seat 1
26 Air Valve Cap 1
27 Air Valve Screw 1
28 Fluid Inlet Coupling 1
29 Needle Guide 1
30 Needle Packing Screw 1
31 Hexagonal Jam Nut 1
32 Cup Coupling Core 1
33 Tube 1
34 Air Vent Valve 1
35 Cup Mounting Yoke 1
36 Cup Locking Lever 1
37 Air Vent Valve 1
38 Cup Cover 1
39 Cup Cover Gasket 1
40 Siphon Tube 1
41 Rivet 2
42 Rivet Cover 2
43 Aluminum Cup 1
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
Parts List and Diagram
Parts List
