Central Pneumatic 90385 - Parts List

SKU 90385 For technical questions, please call 1-800-444-3353. Page 11
Part # Description Qty. Part # Description Qty.
1 BOLT 4 42 BOLT 2
2 CYLINDER HEAD 1 43
CENTRIFUGAL SWITCH SEAT WASHER
2
3 CYLINDER HEAD WASHER 1 44 CENTRIFUGAL SWITCH COVER 1
4A BOLT 2 45 BOLT 4
4B
EXHAUSE VALVE PLATE SPACING
146FAN 1
4C EXHAUSE VALVE PLATE 1 47 RETAINING RING IN SHAFT 2
4D VALVE SEAT 1 48 BOLT 4
5 COLUMN PIN 2 49 BOLT 4
6 INLET VALVE PLATE 1 50 TANK 1
7 CYLINDER UP WASHER 1 51 FLAT WASHER 4
8 CYLINDER 1 52 NUT 4
9 CYLINDER DOWN WASHER 1 53A WHEEL 2
10A PISTON AIR RING 2 53B WHEEL COVER 2
10B PISTON OIL RING 1 54 RETAINING RING IN SHAFT 2
11 RETAINING RING IN HOLE 2 55 EXHAUST ELBOW 1
12 PISTON 1 56A EXHAUST COPPER TUBE 1
13 PISTON PIN 1 56B EXHAUST BOLT 2
14 CONNECT ROD 1 57 PRESSURE RELIEF VALVE 1
15 CRANKCASE 1 58A UNLOAD PIPE NUT 1
16 CRANKSHAFT 1 58B UNLOAD PIPE ASSY. 1
17 IN-SIX ANGLE BOLT 1 59 UNLOAD WATER VALVE 1
18 RUBBER WASHER 4 60 BOLT 1
19 O RING 1 61 RUBBER FOOT PAD 1
20 BOLT 1 62 FLAT WASHER 1
21 STARTING CAPACITOR 1 63 BOLT 1
22 RUNNING CAPACITOR 1 64 ELE. CABLE 1
23 NUT 2 65 PRESSURE GAUGE 1
24 SAW WASHER 2 66 PRESSURE SWITCH 1
25 FLAT WASHER 2 67 PRESSURE RELIEF VALVE 1
26 CONNECTOR 2 68 NIPPER 1
27 NYLON BAND 2 69 AIR CONTROL VALVE 1
29 BOLT 2 70 PRESSURE VALVE 1
30
OVER-LOAD PROTECTOR BRACKET
1 71 PRESSURE GAUGE 1
31 OVER-LOAD PROTECTOR 1 72 OIL LEVELER 1
34 SHAFT OIL SEAL 1 72A OIL LEVELER SEAL 1
35 BEARING 1 73 BOLT 1
36A MOTOR STATOR ASSEMBLY 1 74 SPRING WASHER 1
36B MOTOR ROTOR ASSEMBLY 1 75 CRANKCASE FROM COVER 1
37 BEARING 1 76 CRANKCASE RUBBER SEAL 1
38 WAVE WASHER 1 79 OIL PLUG 1
39 MOTOR BACK COVER 1 80 HANDLE 1
40 BOLT 1 81 BOLT 4
40A TIGHTER WASHER 3 82 MOTOR COVER 1
41A CENTRIFUGAL SWITCH SEAT 1 83 BOLT 2
41B CENTRIFUGAL SWITCH BODY 1 84 BOLT 2
41C BOLT 1 85 AIR FILLER 1
NOTE: Some parts are listed and shown for illustration purposes only and are not available
individually as replacement parts.
PARTS LIST
