Central Pneumatic 93657 - Parts List

Page 14 ;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1 Item 93657
EF;6GH IJ6KFGLIM NFLMG6MFMO6E6GPJ
J,($#%T"#$%,89%U",3(,5
J,($#%T"#$%
Part
U*#4("/$"&8
Qty
1 Screw 4
2 Washer 8
3 Handle 1
4 Cylinder Head 1
5 O-Ring 1
6 Pressure Switch 1
7 Check Valve 1
8 Cylinder Block 1
9 O-Ring 1
10
Cylinder
1
11 Screw 1
12 Valve Plate 1
13 Screw 1
14
Piston Plate
1
15
Piston Ring
1
16 Piston Rod 1
17 Bearing 1
18 Crankshaft 1
19 Front Body 1
20 Paper Pad 1
Part
U*#4("/$"&8
Qty
21 Front Cover 1
22 Bearing 2
23 Stator 1
24 Rotor 1
25 Rear Body 1
26 Power Switch 1
27 Condenser 1
28 Screw 4
29 Rear Cover 1
30
Screw
8
31 Power Cord 1
32 Line Button 1
33 Nipple 2
34 Water Trap/Pressure Regulator 1
35 Pressure Gauge 1
36 Foot 4
37 Pressing Wire Hat 1
38 Snap Ring 1
39 Grommet 1
40 Air Hose (not shown) 1
