SKU 94355 For technical questions, please call 1-800-444-3353 PAGE 15
NOTE:
Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
Part # Description Qty Part # Description Qty
1 Screw (M6 x 25) 1 36 Outlet Valve Support 1
2 Rubber Support 1 37 Valve Plate 1
3 Air Tank 1 38 Inlet Valve Plate 1
4 Drain Valve 1 39 Washer 1
5 Wheel 2 40 Cylinder 1
6 Nut (M8 x 40) 2 41 Hex Screw (M6 x 35) 3
7 Screw (M6 x35) 4 42 Washer 3
8 Kit 1 43 Strap Wheel 1
9 Handle 1 44 Stator 1
10 Safety Valve 1 45 Armature 1
11 Quick Coupler 1 46 Cover 1
12 Screw (ST4 x 20) 13 47 Hex Screw (M5 x 95) 2
13 Tank/Tool Pressure Gauge 2 48 Connection Plate 2
14 Pressure Regulator Knob 1 49 Fan 1
15 1/4” Air Nozzle 1 50 Fan Cover 1
16 1/4" x 1/4" Tie-In 1 51 Valve 1
17 1/4" x 1/4” Fix Ring 1 52 Connector 1
18 Copper Nut 2 53 C5 Washer 2
19 Copper Tube 1 54 Air Nozzle Plug 2
20 Screw (M10 x 25) 1 55 Screw (M5 x 10) 2
21 Bearing (6203) 3 56 Ground Wire 2
22 Connecting Rod 1 57 Air Pressure Switch 1
23 Piston Ring 1 58 Strap 1
24 Back Plate 1 59 Transmission Shaft 1
25 Hex Screw (M6 x 15) 1 60 Eccentric Wheel 1
26 Copper Tube 1 61 Motor Support 1
27 1/2" x 1/2" Fix Ring 1 62 Stator Washer 1
28 Fuse 1 63 Over Heat Sensor 1
29 Upper Cover 1 64 Screw (ST4.2 x 15) 1
30 1/2" x 1/2" Plug 1 65 Strain Relief 1
31 Hex Bolt (M6 x 105) 4 66 Power Cord/Plug 1
32 Cylinder Head 1 67 O-Ring (6000) 2
33 Exhaust 1 68 Carbon Brush Assembly 2
34 Washer 1 69 Screw (ST4 x 10) 4
35 Head Gasket 1 70 Lower Cover 1
71 Air Hose 1
PARTS LIST
