CENTRAL RE Series - Supreme Exhaust Fan Service and Components; Basic Component Identification

Basic Component Identification
5
Lid Open
Safety Chain
Base Lid
(Access to
Grease Duct)
Motor Cover
Wing Nut
Motor & Drive
Assembly Cover
Motor Frame
Assembly
Top Access Door
Blower Wheel
Blower Housing
Discharge Scoop
Wheel Access
Cam Latch
Grease
Reservoir
Grease Reservoir
Drain Valve
Blower Base
Security Pin –
Wheel Access
Motor Cover
Motor Cover
Support Arm
Support Arm
Retainer Clip
Hole in Motor
Frame For
Support Arm
Motor Frame
Assembly
