Generac
®
Power Systems, Inc. 39
Appendix 4 – Exploded Views & Parts Lists
CENTURION 3500 Home Standby Generator
Control Panel - Drawing No. 0E2152-A
ITEM PART NO. QTY. DESCRIPTION
1 0E4914 1 PCB CONTROL ASSEMBLY
2 0E8331 1 BATTERY CHARGER ASSEMBLY
3 083049 1 VOLTAGE REGULATOR
4 049226 6 WASHER LOCK M5
5 075235 6 SCREW HHC M5-0.8 X 30MM
6 049813 4 NUT HEX M6 X 1.0
7 022097 2 WASHER LOCK M6-1/4"
8 022473 2 WASHER FLAT 1/4"-M6
9 0A1658 1 WASHER LOCK SPECIAL 1/4"
10 075476 2 SCREW PPHM M4-0.7 X 16MM
11 048766 1 TERMINAL STRIP, 2 POSITION
12 0E5840 2 CIRCUIT BREAKER 15A PUSH/PULL MAIN RESET
13 0E2042 1 INDICATOR LIGHT
14 0A9611 1 FUSE AGC-7.5A
15 032300 1 FUSE HOLDER
16 0E4494 1 SWITCH ROC DPDT ON-OFF-ON
17 0E5103 1 CONTROL PANEL FRONT
18 057159 1 CIRCUIT BREAKER, DPE
19 031879 2 WASHER FLAT #4
20 043182 2 WASHER LOCK M3
21 051714 2 NUT HEX M3-0.5
22 0D3700 3 NUT FLANGE M6-1.0 NYLOK
23 0E4584 1 BAFFLE, ENGINE INTAKE
24 023484R 2 SNAP BUSHING, 1.25"
25 022264 2 WASHER LOCK #8-M4
26 0D5303 1 WASHER FLAT 0.25" I.D. X 1.00" O.D. ZINC
27 049721 2 SCREW HHC M6-1.0 X 35MM
28 090388 4 SCREW HHTT M6-1.0 X 12MM
29 051715 2 NUT HEX M4-0.7
30 0E6553 1 ISOLATOR/SHOULDER WASHER NYLON
31 0E6553A 1 WASHER NYLON 0.50" X 0.32" X 0.12"
