Generac
®
Power Systems, Inc. 41
Appendix 4 – Exploded Views & Parts Lists
CENTURION 3500 Home Standby Generator
Gn-220 H/SH Engine - Drawing No. 0E2153-A Part 1
ITEM PART NO. QTY. DESCRIPTION
1 0D8433 1 GUARD, FAN
2 0C1069 10 SCREW, HHTT M6-1.0 X 8MM
3 090695F 1 BLOWER HOUSING
4 081810 1 NUT, HEX M16-1.5
5 083312 1 WASHER, M16 CONICAL
6 0E2091 1 BRACKET, GOV SPEED ADJUST
7 0C8917D 1 FLYWHEEL, WITH RING GEAR
8 0C8798A 1 BACKPLATE, ELECTRIC START
9 045756 9 SCREW HHTT M6-1.0 X 10MM
10 082774 1 KEY, WOODRUFF 4 X 19D
11 022129 2 5/16"-M8 LOCK WASHER
12 081990 2 SCREW SHC M8-1.25 X 40MM
13 0D9004A 1 STARTER ASSEMBLY
14 072347 1 SPARKPLUG
15 022097 2 LOCKWASHER, ¼"- M6
16 082981 2 TAPTITE, M6-1.0 X 30MM
17 081675 1 ASSEMBLY, IGNITION COIL
18 0C2018 2 WASHER
19 0D7666 1 BREATHER TUBE
20 090051 1 GASKET, MANIFOLD/ HEAD
21 080316 2 SCREW HHFC M6-1.0 X 30MM
22 090948 1 INTAKE MANIFOLD
23 078631 1 GASKET CARBURETOR/MANIFOLD
24 0E2094 1 CARBURETOR
25 091846 1 GASKET, CARB/ ADAPTOR
26 0D7558 1 ADAPTOR, CARB
27 078643 2 BOLT, CARB MOUNT M6-1.0 X 75MM
28 0D8372 1 GASKET, CARB TO AIRBOX
29 0C2756 1 ASSEMBLY, GOVERNOR LEVER
30 0D7458 1 ROD, GOVERNOR
31 0C3979 1 SPRING, ANTI LASH
32 085953 1 WASHER, CARB WEAR
33 0D8739A 1 ASSEMBLY BRACKET GOVERNOR ADJUST
34 0D9689 1 ELBOW 90D STREET 1/8NPT
35 0E7019 1 SPRING, GOVERNOR
36 083512 1 SCREW HHTT M8-1.2 X 16MM
37 082025 1 NUT HEX LOCK M5-0.8 NYLOCK
38 092984 1 TOP WRAPPER
39 094820 1 PLUG, EXPANSION
40 089739 1 LOWER WRAPPER
41 091848 1 GASKET, OIL PSI PAD
42 0D8778 1 ADAPTER, OIL FILTER
43 0D8803 2 SCREW SHC M6-1.0 X 22MM
44 0A8584 1 SWITCH, OIL- 10 PSI
45 070185 1 FILTER, OIL
52 075281 1 SWITCH, THERMAL 284F
53 043182 2 WASHER LOCK M3
54 0C1085 2 SCREW PPHM M3-0.5 X 8MM
