12
[__][__][ATTRIBUTES
1
][#][ATTRIBUTES
2
][#][ATTRIBUTES
3
][#],
where [__][__] is a 2-digit group for type of the selected zone and ATTRIBUTES
1
, ATTRIBUTES
2
and ATTRIBUTES
3
are 1, 2 and 3 attribute sets for selected zone.
While the system is being within “main programming menu”, you should follow the next steps to program the characteristics of each zone from 1 to
12/16:
1. Select one of the sections from [001] to [012]/[016]. Next, the keypad buzzer will sound 3 confirmation beeps and the panel is waiting for another 2-
digit group to be entered, which stands to the type of the selected zone.
1.1 Set the type of the selected zone by entering a 2-digit group, according to the table below:
Zone
type
KP16LCD (KP16LCDL)
Description
1
line message 2
line message
[00] Type zone: Zxx Not used
Unused zone
[01] Type zone: Zxx Delayed 1
These zone types
are usually used for entry/exit detections. The zones can be violated during the exit delay without causing an
alarm. Once the system/partition is armed, first violation of these zones will start the appropriate entry-delay timer. The user must
disarm the system/partition before the appropriate entry-delay timer elapses or the system will generate an alarm. If a delayed zone
triggers the alarm, the system or the appropriate partition will switch to an instant working mode which will be signaled by a fast
blinking of the corresponding ARMED LED.
There are 2 entry-delay timers:
- the “entry delay 1 timer” which applies to all zones defined as type of “delayed 1” and
- The “entry delay 2 timer” which applies to all zones defined as type of “delayed 2”.
Entry delay 1, delay 2 and exit delay times may be independently set from 1 to 255 seconds within [036] and [037] sections.
The default settings are 30 seconds for each entry delay time and 60 seconds for each exit delay time.
[02] Type zone: Zxx Delayed 2
[03] Type zone: Zxx Follower
This zone type is usually used for interior detection devices, such as motion detectors. The zone will not cause an alarm if it is
violated during the entry delay of the respective partition. However, if the zone is violated before the entry delay has started it will
generate an instant alarm. The follower zone can be violated during the exit delay without causing an alarm.
[04] Type zone: Zxx Instant
This zone type is used for interior detection devices, such as motion detectors
that are not situated within entry/exit area. The
instant zones can be violated during the exit delay without causing an alarm, too, but once the system/partition is armed, the zones
will generate an instant alarm if they are violated (they will trigger the alarm as soon as they are violated).
[05] Type zone: Zxx 24h
The 24-
hour burglary zones are permanently active irrespective of the armed or disarmed system/partition status. This zone type is
useful for connection of glass-break detectors.
[10] Type zone: Zxx Tamper
The sabotage (tamper) zones are permanently active irrespective of the armed or disarmed system/partition status. This type is used
for connection of tamper contacts in the system to prevent any sabotage attempt after the system installation and commissioning.
[11] Type zone: Zxx Panic
The panic zones are permanently active irrespective of the armed or disarmed system/partition status. This type is used for
connection of panic switchers/pedals for a specific event to occur in emergency situations that can be reported to a CS.
[12] Type zone: Zxx Fire
The fire zones are permanently active irrespective of the armed or disarmed system/partition status. This type is used for smoke
detectors. The acoustic warning in case of this zone type violation will be in pulse mode, having the highest alarm priority.
[13] Type zone: Zxx Medical.emerg
The medical emergency zones are permanently active irrespective of the armed or disarmed system/partition status. This type is
used for connection of panic switches/pedals for a specific event to occur in emergency situations that can be reported to a CS.
[14] Type zone: Zxx Keysw/panic
Each time this zone type is activated, the system will arm/disarm as regards to its previous armed/disarmed status. If this zone type
is violated more than 4 seconds, it will generate a panic alarm, too.
[15] Type zone: Zxx Stay keysw.
Each time this zone type is activated, the system will stay arm or d
isarm as regards to its previous armed/disarmed status. If this
zone type is violated more than 4 seconds, then it will generate a panic alarm, too.
[16] Type zone: Zxx Round
If the „guardian rounds” were started previously, any violation of this zone type will make the siren sound for the „ding time” defined
in section [042].If this zone type is activated more than 30 seconds, then it will generate a special event („ambush on round”), too,
if the „guardian rounds” were started previously. No alarm will occur by violation of this zone type.
