- 82 -
WARNI
NG
If the rear w
heel axle nut is not securely tightened, it may result in an unsafe riding condition.
●
Rea
r brake Inspection (Refer to Brake Chapter)
Wear Inspection
●
Stretch the chain taut either
by using the chain adjusters
or hanging a 10 kg object on the chain.
●
Mea
s
u
re the length of 20 links on the straig
ht Part of
the chain from pin center of the 1st pin to pin Center
of the 21st pin.
● If the length exceeds
the service limit, the chain
should be replaced.
Service Limit of drive chain 20-Link Length: 323mm
WARNIN
G
For safety, p
lease use the standard chain. It can not be installed again after cut it short; Have
it installed/replaced by an authorized CFMOTO dealer.
，
Measure
Hanging object
