9. Ignition System
Overhaul standard
Item Standard
Ignition CDI, battery DC digital ignition
Standard DPR7EA-9(NGK)
Optional DR8EA, D7RTC
Spark Plug
Spark plug gap 0.8-0.9mm
Ignition timing Maximum advance
angle
34° CA
Ignition coil >200V Peak voltage
Impulse generator 4V
Special tool
Peak voltage oscillograph 07HGJ-0020100
(Use together with digital muitimeter available in the market with input resistance over
10M/DCV)
9-2
