6. Front Wheel, Front Brake, Suspension, Steering
Overhaul Info………………………..…………6-1
Troubleshooting ………………………………6-2
Front Wheel ………………………….………. 6-3
Front Brake…………………….…………..6-4
Suspension…………………………………6-7
Steering ………………………….…………6-12
Overhaul Information
Operating cautions
Notes
◆
Securely support the vehicle when overhauling the front wheel and suspension system.
◆Refer to chapter 10 for overhaul and inspection of lighting, instruments and switches.
◆Do not overexert on the wheel. Avoid any damage to the wheel.
◆When removing tire, use the special tire lever and rim protector.
Maintenance Standard
Item Standard Service Limit
Longitudinal 0.8mm 2.0mm Rim
Vibration
Lateral 0.8mm 2.0mm
Remained groove -- 3.0mm Tire
Tire Pressure
35kpa(0.35kgf/cm
2
)
--
Front brake Free play (brake lever) 0mm --
Tightening torque
Nut, Tie-rod 40-50N.m
Lock nut, steering stem 110-120N.m
Nut, front wheel axle 110N.m
Fixing bolt/nut, absorber 40-50N.m
Nut, front rim 50-60N.m
Nut, front wheel axle 110-130N.m
6-1
