1. Overhaul Information
Tightening torque
Item Torque N·m(kgf·m) Item Torque N·m(kgf·m)
5mm Bolt, nut 5(0.5) 5mm Screw 4(0.4)
6mm Bolt, nut 10(1.0) 6mm Screw 9(0.9)
8mm Bolt, nut 22(2.2) 6mmSH Bolt with flange, 10(1.0)
10mm Bolt, nut 34(3.5) 6mm Bolt with flange, nut 12(1.2)
12mm Bolt, nut 54(5.5) 8mm Bolt with flange, nut 26(2.7)
10mm Bolt with flange, nut 39(4.0)
For others not listed in the chart, refer to the standard tightening torque.
Notes: 1.Apply some engine oil on the part of screw thread and contact surface
.
Item
Thread Dia.
(mm)
Quantity Torque
N·m(kgf·m)
Front Upper Bolt, Engine M8x60 1 35~45
Rear Upper Bolt, Engine M10x1.25x110 1 40~50
Front Upper Bolt, Engine Bracket M8x14 1 35~45
Rear Upper Bolt, Engine Bracket M8x14 1 35~45
Lower Mounting Bold, Engine M12x1.25x140 2 50~60
Bolt, Swing Arm M10x1.25x70 16 40~50
Bolt, Rear Absorber M10x1.25x50 4 40~50
Bolt, Front Absorber M10x1.25x50 4 40~50
Bolt, Rear Wheel Support M10x1.25x100 4 40~50
Mounting Nut, Rim 901-07.00.02 M20 16 50~60
Nut, Rim Shaft 901-07.00.03 M10 4 110~130
Mounting Screw, Rear Brake Pump M6x25 2 18~22
Bolt, Rear Brake Caliper M10x1.25x20 2 40~50
Bolt, Front Brake Disc 901-08.00.03 M8 8 25~30
Bolt, Front Brake Caliper M8x14 4 35~45
Bolt, Handlebar M8x55 4 20~30
Nut, Tie-rod M10x1.25 4 40~50
Locknut, Steering Stem M14x1.5 1 100~120
Rear Mounting Bolt, Muffler M8x30 1 30~50
Bolt, Exhaust Pipe M8x14 1 30~35
Mounting Bolt, Muffler M8x40 1 30~35
Mounting Bolt, Rear Axle M10x1.25x110 2 40~50
Mounting Bolt, Front Axle M10x1.25x90 1 40~50
Mounting Bolt, Front Axle M10x1.25x25 2 40~50
Bolt, Front Axle Support M8x14 2 35~45
Bolt, Rear Transmission Shaft Rear End 901-30.00.01 6 40~50
Bolt, Rear Transmission Shaft Front End 901-29.00.01 4 35~45
Bolt, Front Transmission Shaft 901-29.00.01 8 35~45
Thermoswitch CF250T-420500 1 28~30
Bolt 1, Front Rack M8x14 2 35~45
Bolt 2, Front Rack M6x12 2 25~30
Bolt, Rear Rack M8x14 4 35x45
