15. Engine Removal, Inspection & Installation
Primary Sliding Sheave
Disassembly
z Remove spacer
z Remove Cam ①and Roller②
Roller
z Check each roller and sliding face for wear and
damage.
Wear and damage: →Replace
Note: rollers should be replaced as a set.
Oil Seal
z Check oil seal lip for wear and damage.
Wear and damage: →Replace
z Remove the oil seal
15-30
