17. Cooling and Lubrication System
z Remove clamps and water hoses
z Release bolts and remove water pump
z Remove O-ring
Note: Do not reuse the O-ring.
z Remove the overflow tube
z Release water pump cover screws, water pump
cover and gasket
z Remove E-ring and impeller
z Remove seal ring ①and rubber seal②
17-8
