17. Cooling and Lubrication System
Oil Seal
z Check oil seal for damage. Pay special attention to
the oil seal lip;
z In case of damage or leakage, replace the oil seal;
Water Pump Body
z Check the mating mace of water pump body with
bearing and mechanical seal.
Damage: →Replace
Impeller
z Check the impeller and shaft for damage.
Damage: →Replace
Assembly and Installation of Water Pump
z Install oil seal with special tool;
Tool: Oil Seal Installer
Note: The stamped mark on the oil seal faces outside
z Apply a little grease to the oil seal lip.
17-10
