1. Overhaul Information
Main Data Table
Item Parameter
Model CF500/CF500-A
Length 2120mm/2320mm
Width 1170mm
Height 1230mm
Wheel base 1290mm/1490mm
Engine type CF188
Displacement 493ml
Fuel type Unleaded gasoline 90 Octane or
above
Dry weight 337Kg/340Kg
Number of Passengers 1 for CF500, 2 for CF500-A
(including driver)
Max. Load 150kg/225Kg
Front 25x8-12
Tire
Rear 25x10-12
Ground Clearance 275mm
Min. turning diameter 4.5m/4.8m
Starting Electrical starting/Recoil starting
Engine type Single cylinder, 4-stroke,
Liquid-cooled, 4 valves, OHC
Combustion chamber type Triangle
Valve Driving type SOHC chain driving
Bore x stroke 87.5mm X 82.0mm
Compression Ratio 10.2:1
Max. power 24Kw/7000 rpm
Max. torque 36N.M/5500 rpm
Lubrication type Pressure & Splash
Oil pump type Rotor
Oil filter type Full flow filter screen
Engine
Cooling type Closed coolant circulation
1-5
