Challenge CLMF2031A - Step 2 - Top Handle Assembly and Adjustment for Operator Height

14
Customer Helpline 0343 515 1906
Step 2 - Top Handle Assembly and Adjustment for Operator Height
Assembly
5a
5c
5b
5
21
5a. Clip the handle
5
into the top half of the grass box
21
5b. Align the fronts end of the top half and the bottom half of the grass collector box. Clip the two
halves together starting at the front.
5c. Once the front clips on either side are secure, work back on either side to secure each clip . This
method will help to keep the two halves of the box aligned.
ATTENTION! Never operate the mower unless the deector guard and grass collector are fully
installed. Risk of injury!
