Challenger Techstar CVT MT525B Series User Manual

7 . ACCESSORIES AND OPTIONS
7.85
Challenger MT500B EU
7
• Memorise the high position by pressing the key «
1
. The
high position value is displayed in the greyed box and is
memorised.
Memorising the low position:
• Place the disc tiller in working position (Fig. 207) using a
linkage cylinder spool valve control.
• Memorise the working position by pressing the key
«
2
.
The memorised working position value is displayed in
the greyed box.
7.14.0.3 - Activating the TIC function
In order to use the TIC function, it must first be activated.
• For this, press the key
«
3
when the window (Fig. 205) is
open. The window (Fig. 208) is displayed.
• Press the key
«
6
when the icon (69 Fig. 208) is green (if
this is not the case, first press the key
«
1
so the icon
(70 Fig. 208) is displayed in green. The TIC function is
then active and the symbol (70 Fig. 208) changes from
OFF to ON.
Z3A-988-08-04
Fig. 206
Z3A-989-08-04
Fig. 207
A
B
1000
2000
790
5.3
10% M
5%
540
2
2000
OFF
1
Z3A-1319-11-04-B
Fig. 208
GEARBOX SETTINGS
ACTIVE MEMORY
HEADLAND
POINTS
EHS VALVES 5-6
EHS VALVES 1-4
REAR DUAL CTRL
RPM
KPH
69
70
