CS100EVO
Sectional Garage Door Opener
Installation and Operating Instructions
Thismanual contains IMPORTANT SAFETY information
DONOT PROCEED WITH THE INSTALLATION BEFORE READING THOROUGHLY
N2966N2966N2966N2966
w w w .chamberlaindiy .com.au
w
w w .chamberlaindiy .co.nz
CARTON INVENTORY
(1) Opener
(2) Hand held transmitter x 2
(3) Remote control visor mount
(4) Curved door arm
(
5) Hanging bracket (2)
(6) Rail bracket
(7) Header bracket
(8) Door bracket
(9) Hardware bag
(10) Rail assembly
(11) C-Rail bracket (2)
(12) Centre Rail Bracket
(
13) Manual
(14 Warning labels
(15) Warranty card
Your garage door opener and rail are packed in a single carton. The PowerLift Plus CS100EVO opener cartons contain the
opener, the rail, its fitting hardware and accessories.
2
RAIL DIMENSIONS
3
NOTE: The Ceiling Fixing Point is measured back from the lintel (see item 1 to 7 of “completed installation”). Also
allow 400 mm back from the fixing point for installation of the powerhead (item 7 to 9 of “completed installation”).
3
DOOR HEIGHT:
Sectional Doors
BELT & RAIL
PART NUMBER:
RAIL LENGTH: CEILING FIXING
POINTS:
Up to 2.2 m 8422 CR5 3000 mm segmented 2840 mm
