12
1. Model 84330AML 1 channel transmitter
2. Model 84335AML 3 channel mini transmitter
3. Model 8747AML Keyless entry system
4. Model 1702AML Keyed outdoor emergency release
5. Model 774AML The Protector System
TM
(IR Beams)
A
CCESSORIES
20
Transmitter wall mount bracket
• Attach bracket to wall using the two flat head screws
provided.
• Slide the transmitter onto bracket.
• Fix the warning against entrapment label near the wall control
(refer section 15).
NOTE: Do not over tighten screws, allow enough clearance to
slide transmitter down onto the bracket.
21
REPLACE BATTERIES IN REMOTES
To prevent SERIOUS INJURY OR DEATH:
- NEVER allow small children near batteries.
- If battery is swallowed, immediately notify doctor.
To replace battery for remote control transmitters - 84330AML & 84335AML, use a screwdriver blade to pry
open the case as shown. Insert battery positive side up.
Assemble again in reverse direction.
To Next Page
