3
MANUAL RELEASE
To operate gate manually, REMOVE top plastic cover on top of
arm. Locate RED release handle.
1. Extend RED handle forward to provide greater leverage.
2. Once extended, pull up on RED handle to release the clamp on
the shaft.
3. Next, locate release pin (shown below right), press button and
pull out. After you have released the clamp and removed the
pin, gate will be free to move manually.
CARTON INVENTORY
Before beginning your installation check that all components
were provided and received undamaged. Refer to list below
for factory provided parts.
Description Qty.
Operator 1
Accessory Shelf 1
Owner’s Manual 1
Warning Signs 2
Sealed 12 Vdc, 7AH Batteries 2
Primary Arm Assembly 1
Emergency Release Pin 1
INTRODUCTION
2. Pull Back
RED HANDLE
3. Press Button & Pull
Pin To Release
1. Extend
