7
Introduction (continued)
Operator Specications
PBG24DCW, PBG24DCG
Parking Operator
CBG24DCW, CBG24DCG
Commercial/Community
Operator
IBG24DCW/IBG24DCG
Industrial Operator
Colors Available White, Charcoal
Usage Classication Class I, II, III, and IV
Maximum Functional Arm
Length
12 feet 14 feet 24 feet
Open / Close Time 1.9 seconds 2.5 seconds 6 seconds
Duty Cycle Continuous
Main AC Supply 120 VAC single phase, 12.5 Amps including Accessory
Outlets
OR 240 VAC single phase, 3.5 Amps
TBD
Optional Transformer Kit When Optional Transformer Kit Model 3PHCONV is installed in the eld, operator
israted phase-to-phase.
208/240/480/575 VAC, 5.2/4.5/2.3/1.9 A, 60 Hz, 1 PH
System Operating Voltage 24 VDC Transformer Run / Battery Backup
Accessory Power 24 VDC, 1A max. for ON + SW (switched)
Solar Power Max 24 VDC, 60 Watts max.
Operating Temperature Without Heater: -20°C to 60°C (-4°F to 140°F)
With Optional Heater: -40°C to 60°C (-40°F to 140°F)
120 VAC accessory power
outlets
6 Amps
When the 3PHCONV kit is used, the outlets are rated 1 Amp
240 VAC not supported
Safety Device Inputs Main control board maximum capacity: Up to 2 safety devices in close direction and
1 safety device in open direction.
Expansion board maximum capacity: Up to 3 safety devices congurable to either
the close or open direction.
ATTENTION: If an edge sensor is being integrated into this system, use a wireless
edge kit. If a wired edge is used, there is risk of wire damage in the gate arm bracket.
See “Site Preparation for Safety Devices” on page 11 for additional details.
Operating Wind Force 60 mph max.
Draft
