33
Item Part Description Qty.
No. No.
1 114134 SLINGER, WATER 1
2 114135 NUT 9
3 114136 SCREW 9
4 114137 PLATE, BACKING, C/W CAPACITOR BRKT. 1
5 110285 GASKET, PUMP 1
6 114139 SEAL, PUMP 1
7 114140 WASHER 1
8 114141 IMPELLER 1
9 114142 WASHER 1
10 114143 WASHER, LOCK 1
11 114144 NUT, IMPELLER (LH THREADS) 1
12 114145 HOUSING, PUMP 1
13 114322 CAPACITOR15μF240VAC 1
*14 115143 PUMP/MOTOR ASSEMBLY COMPLETE 1
208-240VAC/50-60/1PH, 2HP (SEE NOTE)
--- 115144 PUMP/MOTOR ASSEMBLY COMPLETE 1
460-480VAC/50-60/3PH, 2HP
*NOTE:
USE P/N 115143 FOR 208-240V/60/3PH MACHINES.
SEE ELECTRICAL SCHEMATIC FOR WIRING DETAIL
! ATTENTION !
THE MOTOR CANNOT BE ORDERED AS A SEPARATE REPLACEMENT PART.
Wash Pump/Motor Assembly
